Portable Methanol Generator Set for home 5kW - 45kW

Allian Power's leading product, the CM series electronically controlled methanol generator set, is a project guided by the Ministry of Industry and Information Technology of China. It is a national brand product independently designed and developed with complete independent intellectual property rights.

It is an internal combustion engine fueled by renewable energy - methanol, which is equipped to a final product - Methanol generator set, with an output voltage of 230V, 400V, and an AC frequency of 50Hz. It has superior performance, strong power, good economy, and environmental friendliness (the main components of exhaust emissions are CO2 and H2O).

It has passed the EU 2016/1628 emission survey test and 1000 hours of reliability and durability assessment. This is a product to inherit the mature high efficiency advantages of internal combustion engines, also complete the mission of achieving "carbon neutrality" from the energy consumption side.

 Parameter:

Name	Methanol generator set - Open Type
Model	CM5500	CM8500	CM13000	CM16000	CM20000	CM22000	CM27000	CM32000	CM50000
Rated Power	5kW	8/7.5kW	12kW	15kW	18kW	20kW	25kW	30kW	45kW
Rated Voltage	AC230V	AC400V/230V	AC400V/230V	AC400V	AC400V	AC400V	AC400V	AC400V	AC400V
Rated frequency	50 Hz	50 Hz	50 Hz	50 Hz	50 Hz	50 Hz	50 Hz	50 Hz	50Hz
Phase	1P	3P
Rated Current	21.7A	14.4A/32.6A	21.6A/52.5A	27A	32.5A	36A	45A	54A	81A
Power Factor	1	0.8/1.0	0.8/1.0	0.8	0.8	0.8	0.8	0.8	0.8
Rotational speed	3000 r/min	3000 r/min	3000 r/min	3000 r/min	3000 r/min	3000 r/min	3000 r/min	3000 r/min	3000 r/min
Cooling	air cooling	air cooling	air cooling	air cooling	air cooling	water cooling	water cooling	water cooling	water cooling
Methanol Fuel	M100	M100	M100	M100	M100	M100	M100	M100	M100
L×W×H(mm)	735×530×600	735×530×600	813×593×788	960×745×810	960×745×810	1180×840×960	1240×860×1000	1240×860×1000	1350×930×1100
Weight (kg)	90	99	153	195	208	350	380	400	470
